Material (typical): Body:    PC, impact resistant

                          Collect:  POM, stainless steel teeth

                          O-rings:  Nitrile rubber

Performance:

1. Blowing Pressure:  Between temperatures of -10℃ and +60℃, all connectors size can be used for blowing operations at pressures up to 16bar.

2. Burst Pressure:     ＞ 26bar

3. Gas Tightness:     Leakage at 16 bar gas pressure: 1ml/minute approx

                               Leakage at 0.7bar gas pressure: 0.1ml/minute approx

4. Water ingress:     The connectors shall seal against a 6m head of water.

5. Insertion force:     50N max (5kg)

6. Retention force:       25N min (3mm m/d)      55N min (5mm m/d)     125N min (8mm m/d)

(collect not held in)       125N min (10mm m/d)   155N min (14mm microduct)

Specification:
